Extended Reach for Vehicle Extrication
The LD2 Cutter utilizes long straight blades engineered specifically to tackle wide profiles and awkward angles. This extended blade geometry makes the tool suitable for vehicle extrication and cutting structural elements in complex rescue environments.
Safe, Zero-Ejection Chain Severing
Cutting tensioned security chains presents significant projectile hazards during rescue operations. The long straight profile traps chain links within the cutting plane, eliminating the risk of ejection while under hydraulic load.
Cutting Capacity & Profile
- Maximum Cutting Diameter: 22 mm (0.8 in) at the blade junction.
- Target Materials: Vehicle wreck profiles, bars, metal shutters, fences, chains, and cables.
- Blade Configuration: Long, straight cutting edges optimized for large-dimension profiles.
Power Supply & Hydraulic Setup
- Hydraulic Power Units: Connects to LIBERVIT hydraulic power units for standard powered operations.
- Manual Hand Pumps: Operates with a LIBERVIT hand pump for manual or remote deployments.
- Connection Requirements: Requires an adapted hydraulic hose to connect the cutter to the chosen hydraulic power unit or hand pump.
Technical Specifications
| Maximum Blade Opening | 250 mm / 10 in |
| Maximum Thrust | 400 kN |
| Maximum Cutting Capacity | 0.8 inch steel |
| Weight | 13.3 kg |
| Dimensions | 675 x 247 x 235 mm – 26 x 10 x 9.5 inch |
| Transport Handle | included |
| Service Handle | included |
