Teaming up with Rock Exotica, CMC offers a single and double sheave SwivaBiner each certified to NFPA standards. The SwivaBiner is patented, time-tested, made in the USA, and brought to you by two companies committed to quality and service.
NOTE: The carabiner component of the SwivaBiner does not open wide enough to accommodate the CAPTO becket. For the CAPTO becket, please consider using a ProSeries, ProTech, or ProSteel carabiner paired with a ProSwivel Pulley.
- New models certified to NFPA standards
- Combined swivel & pulley reduces system length, allowing more travel
- Pivoting sideplate allows rope loading without disconnecting from anchor
- Double-action detent button prevents accidental opening of the sideplate
- Sheave is mounted on sealed ball bearings for maximum efficiency
- Rotating swivel aligns rope with the direction of pull
- Swivel can be secured using rope, web, or carabiners
- Ergonomic design for anchoring and loading with one hand
- CNC machined for optimal strength & weight
- Prusik minding options facilitate progress capture
- Double sheave pulleys equipped with integrated becket
- Compatible with rope up to 13 mm (1/2 in)
- Ideal for rescue, work at height, and tree care
- Patented, USA Made, time-tested, and proven
Technical Specifications
| Single | Double | |
| MBS | 22 kN | 22 kN |
| Maximum Rope Diameter | 13 mm | 13 mm |
| Weight | 200 g (7 oz) | 298 g (11 oz) |
| Dimensions | 163 x 51 mm | 182 x 51 mm |
| Sheave Material | Aluminum | Aluminum |
CERTIFICATIONS
| NFPA T |
