- The 3-stage Auto-Locking:
- Ergonomic pull-down and twist action
- Beveled edges provide smooth operating surfaces
- Large and ergonomic angled gate opening
- Screw-Lock:
- Features all anodized parts for smooth operation and increased longevity
- Gate design prevents screw-sleeve from detaching from gate
- Snag-resistant keylock nose design
- Large and ergonomic angled gate opening
- 3-stage Orca-Lock
- The ORCA is a unique gate system that lifts up and twists just like many traditional auto-locks, but can be set to remain in the unlocked position. This allows the gate to open easily, just like a non-locker, but close with the security of an auto-lock.
- Set to the “ready” position to open gate like a non-locker
- Use the Orca in situations when quick access is required.
Technical Specifications
| Triact-Lock / Auto-Lock | Screw-Lock | Orca-Lock | |
| MBS Major | 29 kN | 29 kN | 29 kN |
| MBS Minor | 11 kN | 9 kN | 11 kN |
| MBS Open | 9 kN | 9 kN | 9 kN |
| Gate Opening | 24 mm | 24 mm | 24 mm |
| Weight | 80 g | 73 g | 80 g |
| Dimensions | 4.5 x 2.8 in | 4.5 x 2.8 in | 4.5 x 2.8 in |
Certifications
| CE |
